Detail Q Acoustics QB12 Subwoofer Active 12 Inch QB 12
The QB 12 is the first Q Acoustics subwoofer to feature a 12in driver. The big long-throw driver is powered by an ultra low-distortion 220-watt Class D amplifier for tight, powerful bass response, and features a 50mm voice coil for minimal thermal compression. Equally at home with Q Acoustics’ Concept and 3000i range of stereo and centre speakers, Q B12 is designed to be equally adept at reproducing big Hollywood action moments as it is the deep, subtle textures of bass instruments.
220 watts of Class D power driving a long-throw 12in drive unit sounds like a recipe for action. And that’s exactly what it is - no Hollywood blockbuster soundtrack features explosions too loud, too deep or too powerful for Q B12 to handle. But power is nothing without control, and Q B12 is just as comfortable describing the nuances of a double bass or an electronic kick-drum.
Q B12’s sealed, ‘infinite baffle’ cabinet is cleverly braced to deliver maximum stiffness to its motor system and, as a consequence, minimum influence on those deep bass sounds. Mechanical stability = aural satisfaction.
Ease, simplicity and performance A reinforced MDF cabinet with a 36mm-thick baffle, a recessed and hidden terminal panel. Adjustable spiked feet with rubber caps. A choice of elegant, understated finishes. Q B12 is a simple and easy to position and set up as it is invigorating to listen to.
Specifications: Drive unit: 305mm (12in) high-excursion and stiffness paper, straight-sided cone. Peak Amplifier Power: 440 W Continuous Amplifier Power: 220 W Power type: Class D Frequency range: 28 Hz - 300 Hz Crossover frequency range: 40Hz – 250Hz Input impedance: 13 kΩ Input sensitivity: 150 mV Enclosure type: Infinite baffle Enclosure material: MDF Dimensions (H / W / D): 400 x 400 x 446 mm (15.7 x 15.7 x 17.6 in)
