Detail PSU / Power Supply DEEPCOOL PF650 650W 80+ FLAT CABLE TOP
Power Supply DEEPCOOL PF650 650W 80+ FLAT CABLE
80 PLUS Standard Power Supply The DeepCool PF Series Power Supply Unit offers safe and stable power performance with reliable 80 PLUS Standard efficiency and affordable pricing.
TO HIGHER STANDARDS Certified for 80 PLUS 230V EU Standard efficiency that ensures 85% efficiency under typical loading of 50%. Better efficiency translates into lower energy waste and lower temperatures for more cost savings.
SILENT HYDRAULIC BEARING FAN Optimally balanced for low-noise performance, the 120mm fluid bearing fan improves overall life expectancy and reduces friction and vibration.
FLAT BLACK CABLES Stealthy and flexible, the fixed flat black cables are easy to maneuver for cable management while also taking up less space in your system.
RELIABLE PROTECTION Shield against potential risk and damage with overpower, over voltage, and short circuit power protection.
𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀 :
Type : ATX12V V2.4 Product Dimensions : 150×140×86mm (W x L x H) 80PLUS Certifications : 230V EU White Fan Size : 120mm Fan Bearing : Hypro Bearing Topology : Active PFC+Double tube forward Capacitors : Taiwan bulk capacitor Power Good Signal : 100-500ms Hold Up Time : ≥10ms(75% Load) Efficiency : ≥85% Under Typical Load(50% Loading) Protection : OPP/OVP/SCP/UVP Operation Temperature : 0-30°C Regulatory : CB/CCC/CE/UKCA/EAC/RCM/BIS Erp Regulation : ErP 2010 MTBF : 100,000 Hours
Main Power Connector 24 (20+4)Pin x1 EPS 12V Connector 8 (4+4)Pin x2 PCI-E (6+2)Pin x2 - 2Cable SATA x3 + 4Pin Peripheral x1 - 2Cable
