Technical Specifications 80PLUS: APFC 80+ Plus Compliant Efficiency Level:>80% Noise Level: Zero (ECO-ON),<32dBA (at 100% load) Form Factor: Intel ATX 12 V 2.31 Dimensions:140 mm (W) x 150 mm (L) x 86 mm (H) Fan Information: Fan Size 120 mm Fan Control: ECO-ON/OFF Fan Bearing: Fluid Dynamic Bearing Life Expectancy: 50,000 hours at 40 °C, 15 % - 65 % RH Cable Information: Modularity Wired Cabling Cable type: Black tube shield along with colors CPU and PCIe connecor Electrical Features: Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) MTBF @ 25 °C, excl. fan: 100,000 hours AC Input: Full Range AC input (100-240Vac) Protection: OPP, OVP, UVP, OCP, OTP, SCP Safety and Environmental: Safety and EMC CB, CCC,CE Environmental Compliance: RoHS, WEEE, ErP Lot 6
PSU SPECIFICATION AC INPUT: AC 100-240V 50-60Hz 10-5A DC Voltage: +3.3V +5V +12V -12V +5VSB Output: 20A 20A 48A 0.5A 2.5A Watt: 120W 576W 6W 12.5 W Max Output: 700W
