PSU Corsair CV650 NON Modular 80+ Bronze Certified Power Supply new

Detail PSU Corsair CV650 NON Modular 80+ Bronze Certified Power Supply new

Deskripsi PSU Corsair CV650 NON Modular 80+ Bronze Certified Power Supply
SPECIFICATION:
CV650 POWER TABLE
Model RPS0128
Part No. CP-9020211
AC Input Rating
AC Input 100-240V
Input Current 10A-5A
Frequency 47~63Hz
Max Load Max Output
+5V 20A 130W
+3.3V 24A
+12V 52A 624W
-12V 0.3A 3.6W
+5Vsb 3A 15W
Total Power 650W
CV650 DC CABLE LISTING
QTY Cable Connectors
per cable Total
connectors Connector
Spacing Total length
1

ATX Cable 24 pin (20+4)
1 1 - 550mm
(± 10mm)
1

EPS/ATX12V 8 pin (4+4) cable
1 1 - 600mm
(± 10mm)
1

PCIe 8 pin (6+2) cable
2 2 550mm, 120mm 670mm
(± 10mm)
2

SATA Cable (3 SATA)
3 6 450mm, 120mm, 120mm 690mm
(± 10mm)
1

SATA-PATA-PATA-FDD
4 4 450mm, 120mm, 120mm, 120mm 810mm
(± 10mm)

Gambar produk
