PSU Cooler MAster MWE 650 V2 80+ Bronze / Power Supply CM MWE650

Detail PSU Cooler MAster MWE 650 V2 80+ Bronze / Power Supply CM MWE650

Dimensions (L x W x H) 140 x 150 x 86 mm
Fan Size 120mm
Fan Bearing HDB
Fan Speed 2400 RPM
Noise Level @ 20% 11.06 dBA
Noise Level @ 50% 22.3 dBA
Noise Level @ 100% 41.3 dBA
Efficiency 85% Typically
80 PLUS Rating 80 PLUS Bronze
ErP 2014 Lot 3 Yes
Operating Temperature 40°C
Power Good Signal 100 - 500 ms
Hold Up Time >18ms at 100% Full Load@230Vac
MTBF >100,000 Hours
Protections OVP, OPP, SCP, UVP, OTP
Regulatory CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB

ATX 24-Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 8
Peripheral 4-Pin Connectors 4
PCI-e 6+2 Pin Connectors 4
80 Plus Bronze
Non Modular


Active Power Factor Correction

The many processes required by a power supply unit in order to take power directly from the wall or other fixed power source, convert it to the correct output required by the connected components, and then distribute that power to said components safely can be full of risks. This is why it’s important for a PSU to have the right protections and regulations to ensure this process runs correctly.
The MWE Bronze’s Active Power Factor Correction uses a specialized circuit to correct power factor, leading to reduced total harmonics, corrected AC input voltage, and increased overall efficiency output.
