# of Cores 8 # of Threads 16 Processor Base Frequency 2.90 GHz Max Turbo Frequency 4.80 GHz Cache 16 MB Intel® Smart Cache Bus Speed 8 GT/s Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 4.80 GHz Intel® Turbo Boost Technology 2.0 Frequency‡ 4.70 GHz TDP 65 W
Supplemental Information
Embedded Options Available No
Memory Specifications
Max Memory Size (dependent on memory type) 128 GB Memory Types DDR4-2933 Max # of Memory Channels 2 Max Memory Bandwidth 45.8 GB/s ECC Memory Supported ‡ No
Expansion Options
Scalability 1S Only PCI Express Revision 3.0 PCI Express Configurations ‡ Up to 1x16, 2x8, 1x8+2x4 Max # of PCI Express Lanes 16
Package Specifications
Sockets Supported FCLGA1200 Max CPU Configuration 1 Thermal Solution Specification PCG 2015C TJUNCTION 100°C Package Size 37.5mm x 37.5mm
