PROCESSOR INTEL CORE I3 6100 TRAY

Detail PROCESSOR INTEL CORE I3 6100 TRAY

Processor Intel Core i3 6100 3.7GHz Gen6 Tray
Status Launched
Launch Date Q3'15
Lithography 14 nm
Included Items Thermal Solution - E97379
Recommended Customer Price $117.00
-
Performance
# of Cores 2
# of Threads 4
Processor Base Frequency 3.70 GHz
Cache 3 MB SmartCache
Bus Speed 8 GT/s DMI3
TDP 51 W
-
Supplemental Information
Embedded Options Available
Yes
Conflict Free Yes
Datasheet Link
-
Memory Specifications
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-1866/2133, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels 2
Max Memory Bandwidth 34.1 GB/s
ECC Memory Supported
Yes
-
Graphics Specifications
Processor Graphics Intel HD Graphics 530
Graphics Base Frequency 350.00 MHz
Graphics Max Dynamic Frequency 1.05 GHz
Graphics Video Max Memory 64 GB
Graphics Output eDP/DP/HDMI/DVI
4K Support Yes, at 60Hz
Max Resolution (Intel WiDi) 1080p
Max Resolution (HDMI 1.4) 4096x2304@24Hz
Max Resolution (DP) 4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel) 4096x2304@60Hz
Max Resolution (VGA) N/A
DirectX* Support 12
OpenGL* Support 4.4
Intel Quick Sync Video
Yes
Intel InTru 3D Technology Yes
Intel Insider Yes
Intel Wireless Display
Yes
Intel Clear Video HD Technology Yes
Intel Clear Video Technology Yes
# of Displays Supported 3
Device ID 0x1912
-
Expansion Options
Scalability 1S Only
PCI Express Revision 3.0
PCI Express Configurations Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes 16
-
Package Specifications
Sockets Supported FCLGA1151
Max CPU Configuration 1
Thermal Solution Specification PCG 2015C (65W)
TCASE 65C
Package Size 37.5mm x 37.5mm
Low Halogen Options Available See MDDS
Advanced Technologies
Intel Hyper-Threading Technology
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT)
Intel TSX-NI No
Intel 64
