Detail Pressure Sensor Transducer Transmitter 0-4Bar Output

*** PRESSURE TRANSMITTER 0-4Bar 0.4MPa Output 4-20mA, 2 wire, Drat G 1/4 BSPP ***

Specifications:
Capacity Range:0-4 bar(0.4 MPa)
Comprehensive Precision:0.5% FS
Output Signal: 4-20mA (2 wire)
Overload Capacity up to 50 times
Using Temperature Range:-40 to 85 deg C
Power Supply: 12-36 VDC
Electrical connector: DIN 43650A
Pressure Medium:Non-corrosive medium (liquid, water, oil, gas, air, etc)
Temperature Effect on Zero:Typical:0.02%FS/C;Maximal:0.05%FS/C
Temperature Drift on Sensitivity:Typical:0.02%FS/C;Maximal:0.05%FS/C
Shock Resistance:1000g
Housing Material:Stainless Steel
Blast Proof Class:ExiaIICT6
Long-term Stability:less than 0.1%FS/year
Defend Grade:IP68
Pressure Connection: G 1/4 BSPP Male

Wiring:
Pin 1: Supply DC+
PIn 2: Signal output +
