P/N PS-TPD-1000FNFAGx-1 WATTS 1000W FORM FACTOR ATX MODEL TTP-1000AH3FCG MAX. OUTPUT CAPACITY 1000W PEAK OUTPUT CAPACITY 1200W COLOR Black DIMENSION ( W / H / D ) 150mm(W) x 86mm(H) x 160mm(D) WEIGHT 1.8kg PFC (POWER FACTOR CORRECTION) Active PFC POWER GOOD SIGNAL 100-500 msec HOLD UP TIME > 16msec at 100% of full load INPUT CURRENT 15A max INPUT FREQUENCY RANGE 50Hz /60Hz INPUT VOLTAGE 100V – 240V~ OPERATING TEMPERATURE 0°C to + 50°C OPERATING HUMIDITY 20% to 90%,non-condensing STORAGE TEMPERATURE -20°C to + 70°C STORAGE HUMIDITY 5% to 95%, non-condensing COOLING SYSTEM 14cm hydraulic bearing fan EFFICIENCY Meet 80 PLUS®Gold at 115Vac input. MTBF 100,000 hrs minimum SAFETY APPROVAL CE/cTUVus/TÜV/FCC/BSMI/EAC PCI-E 6+2PIN 6x
