Power Supply Cooler Master MasterWatt 650W 80Plus Bronze Modular TUF Gaming

Detail Power Supply Cooler Master MasterWatt 650W 80Plus Bronze Modular TUF Gaming

SEMI-FANLESS MODULAR 80 PLUS BRONZE
POWER SUPPLY
80 PLUS BRONZE CERTIFIED
SEALED LDB FAN BEARINGS
PERFORMANCE DRIVEN TOPOLOGY
5 YEAR WARRANTY
16 AWG PCI-E CABLES

BUILT WITH THE TUF STUFThe 80 Plus Bronze rated MasterWatt TUF Gaming Edition PSU offers semi-fanless operation, modular cabling, thicker than standard market cables, and a 5 year warranty. While under 15% load, MasterWatt TUF Gaming Edition fans aren't spinning, thus reducing the noise, power consumption, and wear on the unit. When the fan is spinning, the Cooler Master designed LDB to fan bearing delivers low noise and a long lifespan. A gradual fan curve increases cooling based on the system's needs, keeping the noise level in check. The higher heat tolerance of the 16 AWG PCI-e cables deliver increased efficiency due to the higher current allowance.

Specifications
Product Name MasterWatt 650 TUF Gaming Edition
Model MPX-6501-AMAAB
ATX Version ATX 12V
PFC Active PFC
Input Voltage 100-240V
Input Current 10-5A
Input Frequency 50-60Hz
Dimensions (L x B x H) 140 x 150 x 86mm
Fan Size 120mm
Fan Bearing LDB
Fan Speed 2100 RPM
Noise @ 20% 13 dBA
Noise @ 50% 14 dBA
Noise @ 100% 29.5 dBA
Efficiency 85% @ Typical Load
80 PLUS Rating 80 PLUS Bronze
ErP 2014 Lot 3 Yes
Operating Temperature 0-40°C
Power Good Signal 100-500ms
Hold Up Time 16ms at 80% load
MTBF >100,000 hours
Protections OCP / OVP / UVP / OPP / OTP / SCP
Regulatory CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
Connectors ATX 24 Pin x 1
EPS 4+4 Pin x 1
SATA x 9
Peripheral 4 Pin x 3
FDD x 1
PCI-e 6+2 Pin x 4

Gambar produk
