Per 4 Pcs Dioda Diode Rectifier Penyearah 6A10 6A 6 Amper 1000V

Elektronik > Elektronik Lainnya > Per 4 Pcs Dioda Diode Rectifier Penyearah 6A10 6A 6 Amper 1000V
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:Pi Digital MedanLihat semua produk Elektronik oleh Pi Digital Medan
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail Per 4 Pcs Dioda Diode Rectifier Penyearah 6A10 6A 6 Amper 1000V

Harga 1 bks isi 4 pcs

6A10

FEATURES :
- Low cost construction.
- Fast switching for high efficiency.
- Low reverse leakage
- High forward surge current capability.
-High temperature soldering guaranteed: 260/10 seconds, 0.375" (9.5mm)lead length at 5 lbs (2.3kg) tension.

MECHANICAL DATA :
- Case: transfer molded plastic
- Epoxy: UL94V - 0 rate flame retardant.
- Polarity: Color band denotes cathode end.
- Lead: Plated axial lead, solderable per MIL - STD - 202E method 208C
- Mounting position: Any
- Weight: 0.07 ounce, 2 grams

SPECIFICATION :
Maximum Repetitive Peak Reverse Voltage: 1000v
Max RMS Voltage: 700v
Max DC Blocking Voltage: 1000v
Maximum Average Forward Rectified Current:6.0Amps
Peak Forward Surge current: 400A
Maximum Instantaneous Forward Voltage at 6.0A :0.95v
Maximum Full Load Reverse Current :1mAmps
Typical Junction Capacitance :150pF
Typical Thermal Resistance : 10
Package: R-6

Gambar produk

Per 4 Pcs Dioda Diode Rectifier Penyearah 6A10 6A 6 Amper 1000V
Per 4 Pcs Dioda Diode Rectifier Penyearah 6A10 6A 6 Amper 1000V
