PCIE X4 to nvme m.2 sata m key b key adapter ssd converter bracket

Detail PCIE X4 to nvme m.2 sata m key b key adapter ssd converter bracket

1. slot paling atas / sebelah sata khusus m.2 sata, satunya lagi khusus m.2 nvme
2. m.2 sata hanya mengambil power dari slot pcie, tetap harus colok kabel sata

M.2 NVME to PCIE Adapter Module Board M+B Key NGFF SSD to PCI-E 3.0 X4 SATA Expansion Card
Feature:
M key M.2 NGFF SSD to PCI-E X4 adapter or B key M.2 NGFF SSD to SATA adapter.
The speed and other properties is not changed, only change the interface type and without any software or drivers.
Support size: 22*30 mm, 22*42 mm, 22*60 mm, 22*80 mm M.2 NGFF SSD.
MACth with two kinds of Metal sheet (length: 8cm, 12cm)
Compatible with any operating system ( On the premise of operating system must be compatible with your hard disk ).
With cooling holes to speed up air circulation.

Specification:
Type: PCIE to M2 Adapter
Internal Interface: M Key + B Key Dual Ports
Support Slots: PCI-E 3.0 X4 GEN3 (Compatible with X4 X8 X16 slot)
Support Devices: PCI-E specification m.2 NVMe and SATA specification M.2 NGFF disk
Support System: for Windows XP/Vista/7/8/10, Linux, MAC OS.
Product Size: 120 X 104 X 18mm/4.72 X 4.09 X 0.71"
Package Weight: 88g

About M.2 NGFF SSD Interface Standard:
Socket 2(B key 2 LANE):there are SATA(such as THNSNH128G8NT/ THNSNH128GDNT/MZNTD256HAGM models of SSD) and PCI-E 2X(such as PX-AG128M6E/PX-AG256M6E/PX-AG512M6E/SD6PP4M models of SSD) two different transfer mode.
Socket 3(M key,4 LANE):PCI-E 4X(such as MZHPU128HCGM MZHPU256HCGL and MZHPU512HCGL models of SSD) transfer mode.

Note:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 1-3mm measuring deviation due to manual measurement.
