Papan Adapter M.2 NGFF SSD Card 12 + 6 Pin Untuk MacBook Air 2010 2011 A1370 A136

Detail Papan Adapter M.2 NGFF SSD Card 12 + 6 Pin Untuk MacBook Air 2010 2011 A1370 A136

Features:
1: The product only support 2012 version Apple MacBook Air model is A1370 A1369 (MC503 MC504 MC505 MC506 MC968 MC969 MC965 MC966).
2: The speed and other properties is not changed, only form conversion interface.
3: Adapter card + M.2 SSD can replace original hard disk, also installed the OS or Windows operating system.

Notice:
1: Only sales adapter card,images of SSD and mainboard is not sales!
2: The adapter card only support 22*80 mm size of M.2 (SATA) SSD,it does not support PCIe X2 or PCIe X4 transfer mode of solid state drives.
3: Some of M.2 SSD is not compatible with apple laptop,Such as the use Sand-Force main control chip of solid-state drives,If it is installed on the Apple computer,The computer will be crashed,or can't install the operating system,or unable to format the hard disk failure, etc.
4: The buyer can't apply for a refund or return because of compatibility issues,because we don't have the condition to compatibility test of all solid-state drives,if there is a compatibility problem please replace other types of hard disk.
5: Please open the trim function after OS installed, it does not need to manually open if install Windows operating system.
6: This product performance is being improved unceasingly, like has the change, not separate informs even slightly.Pictures for reference only, subject to our available products.
About M.2 SSD interface standard:
1. Socket 2(B +M key):there are SATA(such as THNSNH128G8NT/ THNSNH128GDNT/MZNTD256HAGM models of SSD) and PCIe X2(such as PX-AG128M6E/PX-AG128M6E/SD6PP4M models of SSD) two different transfer mode.
2. Socket 3(M key):PCIe X4(such as MZHPU128HCGM and MZHPU512HCGL models of SSD) transfer mode.

About MacBook Air SSD interface standard:
1: 2010 and 2011 version MacBook Air SSD is 6+12 pin, only one side have contact,size is 109 mm*24 mm.It's SATA interface.
2: 2012 version MacBook Air SSD is 7+17 pin, size is 109 mm*24 mm.2012 version MacBook Pro SSD is 7+17 pin, size is 89 mm*33 mm.It's SATA interface.
3: 2013 and 2014 and 2015 version MacBook Air SSD is both side have contact,one sid is 16+12 pin,the other side is 11+14 pin,size is 89 mm*24 mm.It's PCIe X4 interface.
4: 2013 and 2014 and 2015 version MacBook Pro SSD is both side have contact,one sid is 16+12 pin,the other side is 11+14 pin,size is 89 mm*33 mm.It's PCIe X4 interface.

Package Includes:
1 x Adapter Card
