PAKET LENGKAP SISMIN MINSYS MINIMUM SYSTEM ATMEGA328P-PU 16MHZ AVR

Detail PAKET LENGKAP SISMIN MINSYS MINIMUM SYSTEM ATMEGA328P-PU 16MHZ AVR

KIT-0048
========

Deskripsi:

Paket bundling ini kita buat untuk agan yang ingin membuat microcontroller
dengan atmega328p, di paket ini sudah di lengkapi dengan SYSMIN untuk ATMEGA8,
ATMEGA328, Crystal 16MHz yang biasa di pakai untuk microcontroller seperti
arduino, dan di paket ini juga sudah ada IC ATMEGA328P jadi lengkap deh untuk
jadi microcontroller.

Yuk di order sebelum kehabisan :))


Spesifikasi SYSMIN:
- Tegangan Input : 5 V
- Kristal : 8Mhz
- ukuran PCB Board : 7.4cm * 3.4cm
- Tebal Module : 1.66mm


Untuk Kelengkapan modul nya:
- PCB Board : 1 pcs
- 28 Pin Locking seat : 1 pcs
- USB Female : 1 pcs
- DC3-10 Horns seat : 1 pcs
- 8*8 self locking switch : 1 pcs
- 40P pin : 1 pcs
- 8Mhz kristal : 1 pcs
- 22P ceramic capacitors : 2 pcs
- 104 ceramic capacitors : 2 pcs
- 3MM Led Red : 2 pcs
- 6 * 6 Buttons : 1 pcs
- 4.7 K resistors : 2 pcs
- 10 K resistors : 1 pcs

Spesifikasi ATMEGA328

- High Performance, Low Power AVR 8-Bit Microcontroller
- Advanced RISC Architecture
- 131 Powerful Instructions Most Single Clock Cycle Execution
- 32 x 8 General Purpose Working Registers
- Fully Static Operation
- Up to 20 MIPS Throughput at 20 MHz
- On-chip 2-cycle Multiplier
- High Endurance Non-volatile Memory Segments
- K Bytes of In-System Self-Programmable Flash program memory
- K Bytes EEPROM
- Bytes Internal SRAM
- Write/Erase Cycles: 10,000 Flash/EEPROM
- Data retention: 20 years at 85C/100 years at 25C(1)
- Optional Boot Code Section with Independent Lock Bits In-System Programming by
On-chip Boot Program True Read-While-Write Operation
- Programming Lock for Software Security


Peripheral Features:
- Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode
- One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture
Mode
- Real Time Counter with Separate Oscillator
- Six PWM Channels
- 8-channel 10-bit ADC in TQFP and QFN/MLF package Temperature Measurement
- 6-channel 10-bit ADC in PDIP Package

Specifications XTAL 16MHZ:
===============================
- Frequency : 16 MHz
- Package / Case : HC-49/S
- Load Capacitance: 20 pF
- Tolerance : 50 PPM
- Frequency Stability : 100 PPM
- Operating Temperature Range : 0 C to + 70 C
- ESR : 50 Ohms
- Lead Spacing: 4.88 mm
- Length: 11.18 mm
- Width: 4.65 mm
- Mounting Style: Through Hole
- Type: Low Profile HC49/S Leaded Crystal



NOTE: JIKA INGIN DI SOLDERKAN BISA PESAN JASA SOLDER 4 PCS YAH (UNTUK 1PCS
SYSMIN)


Paket :
- 1 x AVR ISP MINIMUM SYSTEM DEVELOPMENT BOARD FOR ATMEGA8 ATMEGA48 ATMEGA88
ATMEGA328

Gambar produk
