Detail Original REX C100 TEMPERATURE CONTROLLER THERMOSTAT THERMOCOUPLE CONTROL C-100

Terbaru di HANSARANG.ID Sama persis foto (3 item)********REX C100 TEMPERATURE CONTROLLER adalah modul controller/thermostat yang menggunakan probe sensor K Type thermocouple.Controller ini memiliki kemampuan pengukuran / pengaturan suhu sampai maksimal 400C.Didalam paket ini tersedia juga Solid State Relay (SSR) 25Amp sebagai pengganti relay mekanikal, dimana SSR berfungsi sama seperti relay yaitu untuk mengatur load / heater.Controller ini dan SSRnya dapat bekerja dengan tegangan 220VAC, sehingga anda tidak memerlukan power supply / adaptor tambahan lagi.Spesifikasi:REX-C100 Temperature Controller KitREX-C100FK02-V*DASize: 48x48x110mmMeasuring accuracy: 0.5%FSCold-end compensation tolerance: ~2C(can be modified by software in 0~50C)Resolution: 14 bitSampling cycle: 0.5 Secpower supply: 220VProcess value (PV), Setting value (SV)Output, alarm and self-tuning can be indicated by: LEDPIN control (including ON/OFF, step-type PID and continuous PID)Self-tuning controlSSR OUTPUTAlarm function output: 1 waySetting value (SV): identical to measuring range (PV)Proportional band (P): 0 ~ full range (ON/OFF control when set to 0)Integral time (I) and Derivative time (D) : 0 ~ 3600 sec (No integral action when set to 0)Heat-reset proportional cycle: 1 ~ 100 secDetective temperature range0 to 400CPower Consumption: 10 VAK Thermocouple Probe CableLength: 0,5mSensor diameter: 4.5mmTemperature range: 0-400CInternal Insulation: FiberglassExternal Shielding: Insulated ShieldingMax.40A SSROutput Voltage Range: Standard TypeOutput Current: 40AInput Voltage: DC 3-32VOutput Voltage: 24-380VACKelengkapan:1pcs REX C100 Controller1pcs K Type Thermocouple Probe1pcs SSR 25A
