Original GY-521 MPU-6050 6 DOF Module Triaxial Accelero gyro MPU6050

Detail Original GY-521 MPU-6050 6 DOF Module Triaxial Accelero gyro MPU6050

( ORIGINAL CHIP )

1. Original Chip: MPU-6050
2. Power supply: 3v-5V power
3. Gyroscope range: +/-250 500 1000 2000/s
4. Acceleration range: +/-2 +/-4 +/-8 +/-16g
5. Communication: standard IIC communication agreement
6. Chip built-in 16 bit AD converter, 16 bits of data output
7. Pin spacing 2.54mm

MPU-6050 is the world's first integrated 6 axis motion processing components, compared to many components, from the combination between the axis of gyroscope and accelerometer in bad problem, reduce the size of a large number of packaging. MPU - 6050 incorporates 3 axis gyroscope, 3 axis accelerator, and can be connected by I2C ports of other accelerator, magnetic sensors, or other Digital Motion sensor processing (DMP: Digital Motion Processor) hardware acceleration, engine by the I2C port mainly in the form of a single data flow, output to the application of the complete calculus 9 shaft fusion technology.
InvenSense motion processing database, processing of position measuring of complex data, reduces the movement processing operation for load of the operating system, and provide a framework for application development API.
MPU-6050 of the angular velocity sensor range is +/-250, +/-500, +/-1000 and +/-500 /SEC (DPS), can be accurate after fast and slow movement, and user programmable control of accelerator is the sensing range is +/-2g and 16g +/-8g and +/-4g. Product transfer from the highest to 400 KHZ of I2C or up to 20 MHZ of SPI.
MPU-6050 can be work under different voltage VDD interface power supply voltage is 2.5V+/-5%, 3.0V+/-5%, or 3.3V+/-5%, logical interface VVDIO power supply of 1.8V+/-5%. MPU-6050 packing size 4x4x0.9mm(QFN), is the size of the revolutionary in the industry. Other features include a built-in temperature sensor, is included in the operating environment only oscillator of plus or minus 1% change.

Gambar produk
