OLT EPON 8 PON 8 SFP 4GE Lan + SFP PX20+++ 7dBm| OLT 8PON 8SFP 4GE

Komputer & Aksesoris > Komponen Network > Switch Internet & PoE > OLT EPON 8 PON 8 SFP 4GE Lan + SFP PX20+++ 7dBm| OLT 8PON 8SFP 4GE
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail OLT EPON 8 PON 8 SFP 4GE Lan + SFP PX20+++ 7dBm| OLT 8PON 8SFP 4GE

Deskripsi : OLT EPON 8 PON SC , 8 SFP, 4 Gigabit LAN ( Uplink )

Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain

- BONUS 1 Unit EPON ONT ( Selama Persediaan msh ada )
- OLT GARANSI 3 BULAN
- SFP GARANSI 1 BULAN


8 ports epon olt
Version:8 ports epon olt
Color:Black
Battery:AC100V~240V
Function:8 ports epon olt
Accessories:Plug

Technical Specification
Parameter Specification
Operating wavelength : 1310(RX) /1490(TX)
Optical power : +2.5 ~ +7dBm
Receiving sensitivity : -27dBm
Max distance : 20km
Max splitter ratio : 1:64
Capacity : 8 SFP PON, each PON supports max 64pcs ONU, total 512pcs ONU
MAC : 16k
Uplink port : 4 SFP ports + 4 Combo(SFP/TP) ports
PON port : 8 SFP 1000M fiber ports

Control port
1 10/100/1000M RJ45 port
1 Console(RJ45), to debug the device
1 USB port
MTBF : 100,000 hours

EPON traits :
Support IEEE802.3ah
Support DBA with minimum1Kbps granularity adjustable
Support 1Gbps up link and down link symmetrical bandwidth
Support AES-128 encryption to each Logical Link Identifier
Support powerful OAM function, implement telnet management, maintenance and upgrade
Support auto discovery and auto register of ONU (real-time operation)
Protocols supported
Support IEEE802.3、IEEE802.3u、IEEE802.3ab、IEEE802.3z
Support IEEE802.1Q VLAN、IEEE802.1d Spanning Tree
Support IEEE 802.1P QoS、IEEE802.3X Flow Control
Support IEEE802.3ad Trunk、IEEE802.1W RSTP

Network management :
Support GUI management based on SNMP
Support WEB management and Telnet GUI management based on CLI

Other functions :
Support 1GMPv1/v2 protocol report, query and leave message mouse
Support DHCP Snooping
Support Ipv4 address learning based at DHCP Snooping
Support ARP Snooping, QoS etc

Gambar produk

OLT EPON 8 PON 8 SFP 4GE Lan + SFP PX20+++ 7dBm| OLT 8PON 8SFP 4GE
OLT EPON 8 PON 8 SFP 4GE Lan + SFP PX20+++ 7dBm| OLT 8PON 8SFP 4GE
