Detail NZXT C550 550Watt Semi Modular 80+ Bronze Power Supply - PA-5B1BB-EU
SPECIFICATION:Key Specs
Dimensions
W 150mm x L 140mm x H 86mm
Material(s)
Steel, PCB and plastic
Compliance Standard
ATX12V v2.4 / EPS12V v2.92
AC Input Rating
100V-240V 8A-4A 50Hz-60Hz
DC Output Rating
Voltage
+3.3V / +5V / +5VSB /+12V / -12V
Max Load
20A / 20A / 2.5A / 45.5A / 0.3A
Voltage Regulation
±5% / ±5% / ±5% / ±5% / ±10%
Ripple & Noise
< 50 mV p-p / < 50 mV p-p / < 50 mV p-p / < 120 mV p-p / < 120 mV p-p
Output Power (watt)
110 / 110 / 12.5 / 546 / 3.6
Total
550
Fan Specs
Dimensions
120 x 120 x 25 (mm)
Speed
2400 ±10% RPM
Airflow
72.90 CFM
Noise
<44 dBA
Bearing
FDB (Fluid Dynamic Bearing)
Energy Efficiency
Rating
80 Plus Bronze
10% loading
82%
20% loading
83%
50% loading
87%
100% loading
83%
Operation
PF Correction
Active@0.96
MTBF
100,000 hours
Operation Temperature
0 to 40°C
Output Connector(s)
24-pin ATX Power
1
4+4-pin CPU power
2
6+2-pin PCIe power
4
SATA Power
6
Peripherals
3
General
Regulations & Certifications (EMC & Safety)
CB / CE / FCC / TUV / cTUV-SUDus / China CCC / Taiwan BSMI R33245/ Australia RCM / EAC / UKCA / WEEE /
Warranty
5 years
Hazardous Materials
RoHS & China RoHS
Model Number
PA-5B1BB-EU
