The Ubiquiti NanoSwitch is an unmanaged switch with four Gigabit Ethernet ports. For its total non‑blocking line rate, the Ubiquiti NanoSwitch supports up to 4Gbps.
Product Features
• 4-PoE Ports • Poe In: RJ45 port supports 10/100/1000 Ethernet connections, and supports 24V passive PoE to power the switch. • PoE Out 1-3: RJ45 ports support 10/100/1000 Ethernet connections, and the three 24V passive PoE ports provide up to 36W PoE output.
Product Specifications
• Dimensions (Excluding Mount): 196.4 x 93.5 x 32.4 mm / ( 7.73 x 3.68 x 1.28") • Weight: 271g / (9.6oz) • Enclosure: White Polycarbonate • Networking Interfaces: (4) 10/100/1000 Mbps Ethernet RJ45 • Supported Voltage Range: Passive 24V PoE In • Power Method: Passive 24V PoE In • Passive PoE Max Wattage per Port: 24V, 1A per Port (24W) • Total Passive PoE Max Wattage: 24V, 1.5A for 3 Ports (36W) • Total Non-Blocking Line Rate: 4 Gbps • Typical Power Consumption: 1.5W • Operating Temperature: -30 to 70° C / (-22 to 158° F) • Operating Humidity: 5 to 95% Noncondensing • ESD/EMP Protection: ± 24kV Air, ± 24kV Contact • Certifications: CE, FCC, IC
