MSI PRO B660M E Intel LGA 1700 B660 DDR4 USB 3.2 SATA3

Detail MSI PRO B660M E Intel LGA 1700 B660 DDR4 USB 3.2 SATA3

MSI PRO B660M-E LGA1700 DDR4 USB 3.2 SATA3

Spesifikasi :

Processor
• Supports 12th/ 13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
• Processor socket LGA1700

• Chipset : Intel® B660 Chipset

Memory
• 2x DDR4 memory slots, support up to 64GB
• Supports 1R 2133/ 2666/ 2933/ 3200 MHz (by JEDEC & POR)
• Max overclocking frequency:
o 1DPC 1R Max speed up to 4600+ MHz
o 1DPC 2R Max speed up to 4000+ MHz
• Supports Dual-Channel mode
• Supports non-ECC, un-buffered memory
• Supports Intel® Extreme Memory Profile (XMP)

Expansion Slot
• 1x PCIe x16 slot (From CPU)
o Supports up to PCIe 4.0 x16
• 1x PCIe x1 slot (From B660 chipset)
o Supports PCIe 3.0 x1

Onboard Graphics
• 1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz
• 1x VGA port, supports a maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz

SATA Ports
• 4x SATA 6Gb/s ports (From B660chipset)

M.2 SSD Slot
• 1x M.2 slot (Key M, from B660 chipset) 1
o Supports up to PCIe 3.0 x4
o Supports up to SATA 6Gb/s
o Supports 2242/ 2260/ 2280 storage devices
o Support Intel® Optane™ Memory
o Supports Intel® Smart Response Technology for Intel Core™ processors

RAID
• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

Audio
Realtek® ALC892/ ALC897 Codec
• 7.1-Channel High Definition Audio

LAN
• 1x Intel® I219V 1Gbps LAN controller
Power Connectors
• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector

USB
Intel® B660 Chipset
• 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
• 6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports available through the internal USB 2.0 connector)

Garansi Resmi 3 Tahun

Gambar produk
