MSI MEG Ai1300P PCiE5 1300watt 80+ Platinum Full Modular - Power Supply

Detail MSI MEG Ai1300P PCiE5 1300watt 80+ Platinum Full Modular - Power Supply

Features :

Supports Nvidia® GeForce RTX® 40 Series graphics cards
ATX 3.0 fully supported
PCIe 5.0 ready, with native 16 pin connector
Software sync with MSI center
Full modular design
Sleeve cables
80 PLUS Platinum certified for high efficiency
100% all Japanese 105oC capacitor
Active PFC design
Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
LLC Half Bridge Topology with DC-DC module design

SPECIFICATION :

PRODUCT NAME
MEG Ai1300P PICE5
FORM FACTOR
ATX
RATED WATTAGE
1300W
EFFICIENCY RATING
80 PLUS Platinum (up to 92%)
MODULAR
Yes (full modular)
FAN SIZE
120 mm
FAN BEARING
Hydro Dynamic Bearing
DIMENSIONS (DXWXH)
160 x 150 x 86 mm
PFC TYPE
Active PFC
INPUT VOLTAGE RANGE
100-240~
INPUT FREQUENCY RANGE
50~60 Hz
PROTECTION
OCP / OVP / OPP / OTP / SCP / UVP
ATX (24 PIN)
1
EPS (8 PIN)
2
PCI-E 5.0 (16 PIN)
1
PCI-E (6+2 PIN)
8
SATA (15 PIN)
16
MOLEX (4 PIN)
4
FDD (4 PIN)
1
