MSI B560M PRO-VDH WIFI (Intel LGA 1200, DDR4, mATX, B560) Motherboard

Merek: MSI | Lihat selengkapnya produk Komputer & Aksesoris dari MSI
Komputer & Aksesoris > Komponen Desktop & Laptop > Motherboard > MSI B560M PRO-VDH WIFI (Intel LGA 1200, DDR4, mATX, B560) Motherboard
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail MSI B560M PRO-VDH WIFI (Intel LGA 1200, DDR4, mATX, B560) Motherboard

Specification :

CPU (Max Support) : i9
Socket : 1200
Chipset : Intel B560 Chipset
DDR4 Memory : 5066(OC) / 5000(OC) / 4800(OC) / 4600(OC) / 4533(OC) / 4400(OC) / 4266(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3333(OC) / 3200(JEDCE & POR) / 3000(JEDCE & POR) / 2933(JEDCE & POR) / 2800(JEDCE & POR) / 2666(JEDCE & POR) / 2400(JEDCE & POR) / 2133(JEDCE & POR) MHz
Memory Channel : Dual
DIMM Slots : 4
Max Memory (GB) : 128
PCI-E x16 : 1
PCI-E Gen : Gen4
PCI-E x1 : 2
SATAIII : 6
M.2 Slot : 2
TPM (header) : 1
LAN : 1x Realtek 8125B 2.5Gbps LAN controller
WiFi & Bluetooth : Intel Wi-Fi 6 AX201, Bluetooth 5.1
USB 3.2 ports (Front) : 2(Gen 1, Type A)
USB 3.2 ports (Rear) : 2(Gen 2, Type A), 2(Gen 1, Type A)
USB 2.0 ports (Front) : 4
USB 2.0 ports (Rear) : 2
Serial ports(Front) : 1
Audio ports (Rear) : Realtek ALC897 Codec
DisplayPort : 1
VGA : 1
HDMI : 1
DirectX : 12
Form Factor : MATX
Operating System : Support for Windows 10 64-bit
