Detail MPU6050 6 Axis Serial Port Accelerometer Gyroscope Sensor for Arduino

Item Description:
Features:

Voltage: 3V ~ 6V
Current: 10mA
Module Size: 15.24mm X 15.24mm X 2mm
Pad pitch: up and down 100mil (2.54mm), about 600mil (15.24mm)
Measuring dimensions: Acceleration: 3-dimensional angular velocity: three-dimensional, attitude angle: 3-D
Range: Acceleration: 16g, angular velocity: 2000 / s
Resolution: Acceleration: 6.1e-5g, the angular velocity: 7.6e-3 / s
Stability: Acceleration: 0.01g, angular speed 0.05 / s
Attitude Stability Measurement: 0.01
Data output frequency 100Hz (baud rate 115200) / 20Hz (9600 baud)
Data Interface: Serial (TTL level), I2C (directly connected MPU6050, no attitude output)
Baud 115200kps / 9600kps

Gambar produk

MPU6050 6 Axis Serial Port Accelerometer Gyroscope Sensor for Arduino
