MOTHERBOARD SOCKET LGA 775 - INNOVATION G41

Detail MOTHERBOARD SOCKET LGA 775 - INNOVATION G41

Spesifikasi :
CPU :
Support Intel LGA 775
Support FSB 533/800/1066/1333mhz CPU

Chipset :
Intel 82G41 + 82801GB

Memory :
Support Dual Channel DDR3 800MHz / 1066MHz memory
Memory up to 8GB

BIOS :
AMI BIOS

I/O Interface :
1x PS/2 Keyboard Port
1x PS/2 Mouse Port
1x COM
1x VGA
4x USB 2.0, Compatible with USB 1.1
1x RJ45
1x 3-in-1 Audio Port (Line in / Line Out / MIC in)

Onboard Interface :
1x 24-pin ATX Power Connector
1x 4-pin ATX 12V Power Connector
2x USB connector, can support 4*USB 2.0
1x F_AUDIO connector
1x F_PANEL connector
1x SPEAKER connector
2x FAN Connector
4x Serial ATA connection port
1x 40-pin IDE port

Integrated Sound :
- With 6-channel HD Audio Codec onboard
- Provides front audio interface, provides front stereo mic interface

Integrated LAN :
- With 10/100Mbps LAN onboard

Expansion Slot :
- 1x PCI Express x16 slot
- 1x PCI slot, conformed to PCI v2.3 specification

Dimension :
- Micro-ATX architechture (16.8 x 21cm)

Gambar produk
