Motherboard MSI MPG Z590 Gaming Plus LGA 1200

Detail Motherboard MSI MPG Z590 Gaming Plus LGA 1200

PROCESSOR

Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel ® Core™ Processors, Pentium® Gold and Celeron® Processors 1

Processor socket LGA1200
Please go to intel.com for compatibility information.


CHIPSET
Intel® Z590 Chipset
MEMORY
4x DDR4 memory slots, support up to 128GB1
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC & POR)1
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel ® CPU (by JEDEC & POR)1
Max overclocking frequency:
1DPC 1R Max speed up to 5333 MHz
1DPC 2R Max speed up to 4700+ MHz
2DPC 1R Max speed up to 4400+ MHz
2DPC 2R Max speed up to 4000+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)

EXPANSION SLOTS

3x PCIe x16 slots
Support x16/x4/x4
PCI_E1 (From CPU)
Supports up to PCIe 4.0 for 11th Gen Intel® CPU
Supports up to PCIe 3.0 for 10th Gen Intel® CPU
PCI_E31 & PCI_E5 (From Z590 chipset)
Support up to PCIe 3.0
2x PCIe 3.0 x1 slots (From Z590 chipset)
PCI_E3 will be unavailable when installing M.2 SSD in the M2_2 slot.

ONBOARD GRAPHICS
1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz1 2
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz1 2
Available only on processors featuring integrated graphics.Graphics specifications may vary depending on the CPU installed.

MULTI-GPU

Supports 2-Way AMD® CrossFire™ Technology
