MOTHERBOARD MSI MAG Z590 GAMING PLUS

Detail MOTHERBOARD MSI MAG Z590 GAMING PLUS

SPESIFIKASI
CPU (MAX SUPPORT)
i9

SOCKET
1200

CHIPSET
Intel® Z590 Chipset

DDR4 MEMORY
5333(OC)/ 5200(OC)/ 5000(OC)/ 4800(OC)/ 4600(OC)/ 4533(OC)/ 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz

MEMORY CHANNEL
Dual

DIMM SLOTS
4

MAX MEMORY (GB)
128

PCI-E X16
3

PCI-E X1
2

SATAIII
6

M.2 SLOT
3

RAID
0/1/5/10

LAN
1x Intel® I225-V 2.5G LAN

USB 3.2 PORTS (FRONT)
1(Gen 2, Type C), 2(Gen 1, Type A)

USB 3.2 PORTS (REAR)
1(Gen 2x2, Type C), 3(Gen 2, Type A), 2(Gen 1, Type A)

USB 2.0 PORTS (FRONT)
4

USB 2.0 PORTS (REAR)
2

AUDIO PORTS (REAR)
Supports S/PDIF output (Realtek® ALC4080)

DISPLAYPORT
1

HDMI
1

DIRECTX
12

FORM FACTOR
ATX

CROSSFIRE
Y

OPERATING SYSTEM
Support for Windows® 10 64-bit

Gambar produk
