Motherboard MSI MAG B560 TORPEDO ATX LGA1200 HDMI DP MSI B560

Detail Motherboard MSI MAG B560 TORPEDO ATX LGA1200 HDMI DP MSI B560

FEATURES
Extended Heatsink Design
MSI extended PWM heatsink and enhanced circuit design ensures
even high-end processors to run in full speed.
2.5G Plus Gigabit LAN
Onboard 2.5G, Gigabits LAN with LAN manager, delivers the
better online network experience without lag.

SPECIFICATIONS
Model Name : MAG B560 TORPEDO
CPU Support : Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
CPU Socket : LGA 1200
Chipset : Intel® B560 Chipset
Graphics Interface :
1x PCIe 4.0 x16 slot
1x PCIe 3.0 x16 slot
Support 2-way AMD® CrossFire™ Technology
Display Interface : HDMI, Displayport – Requires Processor Graphics
Memory Support : 4 DIMMs, Dual Channel DDR4-5000(OC)Mhz
Expansion Slots : 1x PCIe 3.0 x1 slot
Storage :
1x M.2 Gen4 x4 slot
2x M.2 Gen3 x4 slots
6x SATA 6Gb/s ports
USB ports :
1x USB3.2 Gen 2x2 20Gbps (Type-C)
1x USB 3.2 Gen 2 10Gbps (Type-C)
6x USB 3.2 Gen 1 5Gbps (Type-A)
8x USB 2.0
LAN :
Realtek® 8125B 2.5G LAN
1x Intel® I219-V 1G LAN
Audio : 8-Channel (7.1) HD Audio with Audio Boost(ALC897)
