Motherboard ICONIX H110 SOCKET 1151 M.2 SLOT NVME 2280 MOBO H110 1151

Detail Motherboard ICONIX H110 SOCKET 1151 M.2 SLOT NVME 2280 MOBO H110 1151

rocessor

Support Intel® Socket 1151 for 6th/7th/8th/9th Generation Core™i7/ Core™ i5/Core™ i3/Pentium®/Celeron® Processors

Supports Intel® 14 nm CPU

Supports Intel® Turbo Boost Technology 2.0


Chipset Intel® H110 Chipset
Memory

Support


2 * DDR4 2133MHz DIMM ,Max. 64GB

Dual channel memory architecture


Graphic

Integrated Graphics Processor- Intel® HD Graphics support

Multi-VGA output support : HD / VGA ports


Slots
1 x PCIe x16 3.0/2.0 slot

1 x PCIe x16 2.0 slot

Storage
1 x M.2 Socket, Supports 2260/2280 SSD

4 x SATA 6Gb/s Ports

LAN Realtek Chip, 1 x 100M（Optional 1000M）
Audio Realtek Chip, ALC 6-channel audio
USB 4 * USB 3.0 port (2 at back panel, blue, 2 at mid-board)
6 * USB 2.0 port (2 at back panel, black, 2 at mid-board)


Back Panel I/O
1 x VGA Port

1 x HDMI Port

1 x LAN (RJ45) Port

2 x USB 3.1 Gen 1 Ports(Blue)

4 x USB 2.0 Ports

3 x flexible audio jacks

Internal I/O

1 x USB 3.1 Gen 1 connector（19pin)， supports 2*USB 3.1 Gen 1 ports

1 x USB 2.0 connector， supports 2*USB 2.0 ports

4 x SATA 6Gb/s Ports


2 x 4 -pin CPU_FAN/SYS_FAN connectors

1 x 24-pin ATX power connector

1 x 4-pin 12V ATX Power connectors

1 x F_Audio connector

1 x Internal Speaker connector

1 x F_Panel connector


Dimension 215 x 170mm
