MOTHERBOARD GIGABYTE B460 AORUS PRO AC

Detail MOTHERBOARD GIGABYTE B460 AORUS PRO AC

Intel® B460 AORUS Motherboard with Direct 8+2 Phase Digital VRM Design, Advanced Thermal Design with Enlarged Heatsink ,Dual Ultra-Fast NVMe PCIe 3.0 x4 M.2 with Thermal Guards, Intel® 802.11ac Wave2 2T2R WIFI & BT 5, Intel® 2.5 GbE LAN, USB 3.2 Gen2 Type-C™, RGB FUSION 2.0
• Supports 10th Gen Intel® Core™ Series Processors
• Direct 8 Phases Digital VRM Solution
• Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
• Advanced Thermal Design with Enlarged Heatsink
• Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
• Dual Ultra-Fast NVMe PCIe 3.0 x4 M.2 with Thermal Guards
• Intel® 802.11ac Wave2 2T2R WIFI & BT 5
• Blazing Fast Intel® 2.5 GbE LAN with cFosSpeed
• Intel® USB 3.2 Gen2 Type-C™ Support
• ALC 1220 120dB SNR HD Audio with WIMA & Nichicon MW Audio Capacitors
• RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
• Easy and Quick Installation: Pre-installed IO Shield
• Q-Flash Plus Update BIOS without Installing the CPU、Memory and Graphics Card
• Intel® Optane™ Memory Ready


SPESIFIKASI
• CPU
1. Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1200 package
2. L3 cache varies with CPU
(Please refer to "CPU Support List" for more information.)
• Chipset
1. Intel® B460 Express Chipset
• Memory
1. Intel® Core™ i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz
2. Intel® Core™ i5/i3/Pentium®/Celeron® processors:
Support for DDR4 2666/2400/2133 MHz
3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
4. Dual channel memory architecture
5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
7. Support for Extreme Memory Profile (XMP) memory modules
(Please refer to "Memory Support List" for more information.)
• Onboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support:
1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
2. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
Maximum shared memory of 512 MB
• Audio
1. Realtek® ALC1220-VB codec
* The back panel line out jack supports DSD audio.
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF Out
• LAN
1. Intel® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
• Wireless Communication module
Intel® Wi-Fi 9260
1. Wi-Fi 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
2. BLUETOOTH 5.0
3. Support for 11ac 160MHz wireless standard and up to 1.73 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
• Expansion Slots
1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Expres
