Motherboard ASUS TUF GAMING B660-PLUS WIFI D4 LGA 1700 ATX

Detail Motherboard ASUS TUF GAMING B660-PLUS WIFI D4 LGA 1700 ATX

Asus TUF Gaming B660M-Plus adalah motherboard pada komputer untuk memastikan kinerja komputer optimal. Memiliki fitur socket CPU LGA 1700 yang didukung dengan tipe processors gen 12. Dilengkapi dengan tipe chipset Intel B660, slot RAM DDR4 dengan kapasitas 128 GB. Juga dibekali ethernet, TUF LANGuard sehingga cocok untuk bermain game online.

CPU
- Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset
- Intel B660

Memory
4 x DIMM, Max. 128GB, DDR4 5333(OC) /5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*

Graphics
- 1 x DisplayPort**
- 1 x HDMI® port***
* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.

Expansion Slots
- Intel® 12th Gen Processors
* 1 x PCIe 5.0/4.0/3.0 x16 slot(s)
- Intel® B660 Chipset*
* 1 x PCIe 3.0 x16 slot (supports x4 mode)
* 2 x PCIe 3.0 x1 slots

Storage
- Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
- Intel® 12th Gen Processors
* M.2_1 slot (Key M), type 2242/2260/2280/22110
# Intel® 12th Gen processors support PCIe 4.0 x4 mode.
- Intel® B660 Chipset**
* M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)
* M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
* 4 x SATA 6Gb/s ports

Ethernet
- 1 x Intel® 2.5Gb Ethernet

Wireless & Bluetooth
- Wi-Fi 6
- 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5GHz frequency band
- Bluetooth v5.2

Form Factor
- ATX
- 30.5cm x 24.4cm

Gambar produk
