Motherboard ASUS PRIME H610MK D4 Micro ATX H610 DDR4 LGA 1700

Detail Motherboard ASUS PRIME H610MK D4 Micro ATX H610 DDR4 LGA 1700

ASUS PRIME H610M-K D4 INTEL H610 LGA 1700 MICRO ATX

Spesifikasi:
CPU:
Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset: Intel® H610 Chipset

Memory:
2 x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)

Graphics:
1 x D-Sub port
1 x HDMI® port**
** Supports 4K@60Hz as specified in HDMI 2.1.

Expansion Slots:
Intel® 12th Gen Processors:
1 x PCIe 4.0 x16 slot
Intel® H610 Chipset:
1 x PCIe 3.0 x1 slot

Storage:
Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel® H610 Chipset
M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)
4 x SATA 6Gb/s ports
* The M.2 slot shares bandwidth with the SATA6G_4 port. When a device in SATA mode is installed on the M.2 slot, the SATA6G_4 port cannot be used.

Ethernet
1 x Realtek 1Gb Ethernet

USB:
Rear USB (Total 6 ports)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 4 ports)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports

Garansi Resmi 3 Tahun

Gambar produk
