CPU Intel® Socket 1150 for New 4th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® 22 nm CPU Supports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to wwwasuscom for CPU support list Chipset Intel® H81 Memori 2 x DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * Refer to wwwasuscom or user manual for the Memory QVL (Qualified Vendors Lists). * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Due to Intel® chipset limitation, DDR3 1600 MHz and higher memory modules on XMP mode will run at the maximum transfer rate of DDR3 1600 Mhz. Grafis Integrated Graphics Processor Dukungan output Multi-VGA : DVI/RGB port - Mendukung DVI dengan resolusi maks. 1920 x 1200 @ 60 Hz - Mendukung RGB dengan resolusi maks. 1920 x 1200 @ 60 Hz Maximum shared memory of 1024 MB Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™ Slot Ekspansi 1 x PCIe x16 2 x PCIe 2.0 x1 Storage Intel® H81 chipset : 2 x SATA 6Gb/s port(s), yellow 2 x SATA 3Gb/s port(s), dark brown Supports Intel® Rapid Start Technology, Intel® Smart Connect Technology *1 LAN Realtek® 8111G, 1 x Gigabit LAN Controller(s) Audio Realtek® ALC887 8-Channel High Definition Audio CODEC *2 - Supports : Jack-detection, Front Panel Jack-retasking Port USB Intel® H81 chipset : 2 x USB 3.1 Gen 1 port(s) (2 at back panel, blue) Intel® H81 chipset : 6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)
