Informasi teknis: > Dualband GSM 900/1800 MHz. > Mendukung Data / SMS / Voice / Fax. > Max Power Output: 2W (900 Mhz), 1 W (1800 MHz). > mendukung Group 3 Fax (Kelas 2) GPRS # Kelas B, Kelas 10 (1 2Rx Tx). > SimToolKit Kelas 2. > AT command set (GSM 07,05, 07,07 dan fungsi AT pada GSM WAVECOM). > Protokol TCP / IP stack tersedia untuk data dan Internet. > Maksimum tingkat pengaturan baud: 115200 bps.
Fitur SMS: > Teks dan PDU > Point to point (MT / MO) > Cell Broadcast > Karakter UCS2
Koneksi Antar Muka: > SIM > 15 pin konektor Sub-D (serial dan koneksi audio) > 4-pin konektor power supply > SMA konektor antena
Dimensi: > Secara keseluruhan ukuran: 88 mm x 60 mm x 26 mm > Berat: 100 g > Rentang temperatur: -15 ° C hingga 50 ° operasi C, -20 ° C sampai 65 ° C penyimpanan
