Detail Module hsm-20g hsm20g hsm20 temperature humidity sensor
Specification:- Input Voltage: DC 5.0 +/- 0.2V
- Output Voltage: DC 1.0 - 3.0V
- Measurement accuracy +/- 5% RH
- Operating current maximum: 2mA
- Storage RH range 0 to 99% RH
- Operating RH range 20 to 95% RH (100% RH intermittent)
- Transient Condensation 3 %RH
- Temperature storage -20C to 70C
- Temperature operating 0C to 50C
- Hysteresis (RH@25C) Max 2%RH
- Long term stability (typical drift per year) +/- 1.5%
- Linearity
- Time Response (63% step change) 1 min
- Dimension (L*W) 34mm * 22mm
