Modul Panel Step Down/Cv 5a Adjustable Dengan Display Led
Deskripsi singkat
Perlengkapan Rumah > Perkakas > Electrical Tester & Multimeter > Modul Panel Step Down/Cv 5a Adjustable Dengan Display Led
- Pengiriman Ekspres
- Barang yang diperiksa
- Bayar di tempat berlaku
- Kualitas, Prestise
- Pengembalian produk
- Dukung pembuatan faktur
Produk Terkait
Detail Modul Panel Step Down/Cv 5a Adjustable Dengan Display Led
【Friends Welcome to #OlahragaOutdoorElektronik# store , If you love our products, please clickWhy choose our store?
» 〖 FREE SHIPPING 〗 RM0.00 for order > IDR232,000 (mix products) from our store.
» 〖 READY STOCK 〗 for all of our products.
» 〖 SAME DAY POST 〗 for all orders made before 5pm.
» 〖 FAST DELIVERY 〗 post from Overseas, normally shipping out 1-2 days.
» 〖 WARRANTY PROGRAM 〗 if you are not satisfy with our product or whatsoever, please do contact us to learn more without hesitate
» Working hour : Mon - Sta @ 09:00 -20:00
»〖 Follow #OlahragaOutdoorElektronik# 〗 You can get IDR2000 discountFeatures:
Universal receiver.
100% Brand New
Module Properties: non-isolated constant current and voltage module
Rectification: non-synchronous rectification
Input voltage: 5V-32V
Output voltage: 1.27V-30V
Output current: adjustable maximum 5A
Conversion efficiency: 95% (the highest)
Switching frequency: 300KHz
Output ripple: 50mV (max) 20M bandwidth
Load Regulation: ± 0.5%
Voltage Regulation: ± 2.5%
Operating Temperature: -40℃to +85℃
Size: 51 * 26.3 * 14 (L * W * H) (mm)
Voltmeter Ammeter
Measurement accuracy: 0.1%
Refresh rate: about 200ms / times\
Display: 0.28"digital tube
Current Range 0A-5A
Voltage range 5V-30V
Display Color Red
Package Included:
1 X 5A Adjustable Display Step Down Charge Module LED Panel Ammeter Voltmeter
#DIYMORE #Adjustable #CC/CV #Step-Down #Module #LED #Panel #Voltmeter #Ammeter
Delivery Info :
» All items are dispatched same day from Monday - Saturday (except Sunday & public holiday).
» Our order cut off time is 5pm, any order after 5pm will dispatch the following day.
» Please make sure that the address you provided is accurate, we DO NOT responsible for any mistakes that did by the customer.
» If you do not receive your goods by the time it mentioned, please do contact or email without hesitation.
【After sales policy】 We will provide a free replacement or repair service in the following cases:
1. We make logistics mistakes
2.We send the wrong product
3.Product have quality problems which is not damaged by human factor within warranty period, the warranty period will depends on specific product warranty
4.You receive a fake one
»Still have questions? ….Let's CHAT NOW!
Gambar produk
