Modul Board BMS Pelindung Charger Baterai Lithium Li-ion 18650 2S 3A 7.4V 8.4V

Detail Modul Board BMS Pelindung Charger Baterai Lithium Li-ion 18650 2S 3A 7.4V 8.4V

Features:
1) high-accuracy voltage detection circuit;
2) terminal of the charger using high voltage device;
3) Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit);
4) MOS transistor can control the battery charge and discharge;
5) low standby current consumption.


Description:
100% brand new and high quality
Over charge voltage:4.25-4.35v±0.05v
Over dishcarge voltage: 2.3-3.0v±0.05v
Max continuous current:3A
Max peak current:5A
Working temperature:-40---+50
Storage Temperature:-40-- +80
Small current:less than 3uA
Life cycle :more than 50000hours
Resistance:Less than 45m
Short cut protection :Protectable,charge can repair


Package include:
1 x 18650 Charger Protection Board



Notes:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 1-3cm measuring deviation due to manual mearement.

Gambar produk
