Mini Video Card Capture Grabber HDMI Video Card Support 4K Input USB

Detail Mini Video Card Capture Grabber HDMI Video Card Support 4K Input USB

Product Name: Video Capture Card USB

Color: B lack

Size: 64x28x13mm

Manufacturing method: Semi mechanical

Material: Metal

Features:

* Support input max resolution 3840x2160@30Hz

* Support output max resolution 1920x 1080@30Hz

* Support 8/10/12bit deep color.

* Support AWG26 HDMI standard cable: input up to 15 meters,1080P and below resolution

* Support most acquisition software, such as VLC,OBS,Amcap, etc.

* Support Windows and MacOS

* Conform to USB Video and UVC standard

* Conform to USB Audio UAC standard

* Without external power supply, compact and portable.

*HDCP Content Encryption HDMI Devices is not allowed for capture



Specifications:

HDMI resolution: Max input can be 3840x2160@30Hz

Support video format :8/10/12bit Deep color

Video output format:YUV,JPEG

Support audio format: L-PCM

Input cable distance:15m,AWG26 HDMI standard cable

Max working current:0.4A/5VDC

Operating Temperature range: -10 to +55C

Applicable scene: Streaming Media Software And Live Platform

Package Contents:

1X Video capture

1X User manual
