Mini FPV Goggle 5.8G 40CH 480x320 Double Antenna Built 3.7V 1200mAh Bl

Detail Mini FPV Goggle 5.8G 40CH 480x320 Double Antenna Built 3.7V 1200mAh Bl

Descroption:
Double Antennas
Built-in 3.7V 1200mAh Battery
Support a key search frequency
RaceBand 40 channel Auto-Searching
Real-time video return 5.8G

Feature:
● Small size and light weight;
● Low power consumption, Working current 300~330mA;
● Double antenna reception to make the signal more stable;
● RaceBand 40 channel, Auto-Searching;
● 3.0 Inch 480*320 dot high brightness LCD screen;
● Built-in super sensitiveness 5.8GHz 40ch receiver, especially with
RaceBand;
● Built-in 3.7V/1200mAh high-capacity Li-ion polymer Battery;
● Universal USB charging interface;
● Real-time video return, Very low time-delay;
● Bilingual menu in support of Chinese and English;
● Support external video signal input;
● Support AV signal output (Connect external DVR);

Specification:
Name: Mini FPV Goggles
LCD Screen: Screen size: 3.0 Inch
Resolution: 480*320
Display Ratio: 16:9
View Angle: 6 o'clock
Brightness: 350cd/m² with high brightness backlight LED

Video delay: Video time-delay less than 20ms
Lens: 4X Fresnel Lens, 92% transparent rate no distort of light
Interface Antenna: 2 X RP-SMA male
USB : To charge the battery
AV Jack: External video signals input or internals AV signal output
Languages: English and Chinese
Power Supply Power adapter: DC5V/1A (USB interface)
Battery: 3.7V/1200mAh,Each full charge revive around 2.5hr working time

Power Consumption:
*The device operating current of 300~330mA at 3.7~4.2V;
*Built-in battery maximum charge current of 500mA;
