Mini 3a 12-24V To 5V DC-DC Step Down Module Buck Converter Adjustable

Detail Mini 3a 12-24V To 5V DC-DC Step Down Module Buck Converter Adjustable

HARAP BACA DESKRIPSI PRODUK SEBELUM MEMBELI !

- Kemasan SEGEL PACK, belum dicoba. Membeli berarti setuju, no RETUR & no KOMPLAIN.
- Produk bisa dilihat = ready stok, pembelian dengan qty banyak harap ditanyakan dulu.
- Produk yang dikirim diusahakan sesuai pada foto utama & harap tidak mempermasalahkan perbedaan, jika ada tulisan/ gambar/logo pada board (fungsi tetap sama).

- In DC 12 - 24v
- Out 1.8v, 2.5v, 3.3v, 9v, 12v
- ADJ (bisa diatur dengan trimpot/ vr)
- Board 20*11 mm

Cara setting output nya dengan cara dihubungkan/ disolder pada sisi bawah board dengan timah sesuai dengan tegangan yang diinginkan.

Informasi lain:
1: The max out current 3A, long-running 2.1A, sufficient margin.
2: The new design, circuit design does not require electrolytic capacitors and tantalum capacitors (electrolytic capacitor life is short, tantalum risk of explosion). Now with the use of high-end large-size solid ceramic capacitor circuit (MCC) 2 Ke.
3: The new program uses synchronous rectification circuit conversion efficiency is very high, in turn 5V 0.7A 6.5V when efficiency up to 97.5%, 12V turn 5V 1A, they also reached 94%, unlike some peers efficiency is only 60-70% . (Efficiency test removed the input reverse polarity protection diode and fuse drop).
4: Big shielded inductor current, low resistance, to maximize conversion efficiency. Reduce heat.
5: Ultra-small size, 20 (L) * 11 (W) * 5 (H) mm, the whole network to a minimum.
6: Ultra-low quiescent current, quiescent current of 0.85 mA. Connected to the car battery without adding switches can be connected to the cigarette lighter line or the ACC power cable line.
7: Output Integrated adjustable and fixed voltage, fixed output does not need customization, direct can be very voltage, potentiometer can adjust, versatility is very strong on the board under the spot welding
8: Integration enabled port, default mode of operation, low close, bring convenience to control
9: 78 series can be used to replace linear regulators, such as 78057812, and so on.

Gambar produk
