MIKROTIK RB 912UAG 2HPND OUT BASEBOX 2

Detail MIKROTIK RB 912UAG 2HPND OUT BASEBOX 2

POSTEL : 74588/SDPPI/2021

VIDEO PRODUK :
youtube.com/watch?v=IhM670xUzXo

The BaseBox2 is an outdoor 2.4Ghz wireless device, based on our popular RB912 model, fitted with two SMA connectors for antennas, and a cable hood for protection against moisture. Also available are three additional places for antenna connectors, in case you wish to use the BaseBox miniPCIe slot for one more wireless interface to make a dual band device, or a 3G/4G modem.



The case can be opened with one hand, and is protected against the elements. USB, Ethernet and a Grounding wire exits are provided on the bottom, behind a protective door.



Comes with a mounting loop for tower/pole mounting, and a separate DIN rail mount is also provided. Package also includes a PoE injector and power supply unit.

Product code RB912UAG-2HPnD-OUT
Architecture MIPSBE
CPU AR9342
CPU core count 1
CPU nominal frequency 600 MHz
License level 4
Operating System RouterOS
Size of RAM 64 MB
Storage size 64 MB
Storage type NAND
Tested ambient temperature -40C to 70C
Powering
Details
PoE in Passive PoE
PoE in input Voltage 8-30 V
Number of DC inputs 1 (PoE-IN)
Max power consumption 10 W

Wireless
Details
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz standards 802.11b/g/n
Wireless 2.4 GHz chip model AR9342

Ethernet
Details
10/100/1000 Ethernet ports 1

Peripherals
Details
Number of SIM slots 1 Modem (Mini SIM)
MiniPCI-e slots 1
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1

Other
Details
PCB temperature monitor Yes
Voltage Monitor Yes

Wireless specifications
2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 30 -100
11MBit/s 30 -94
6MBit/s 30 -96
54MBit/s 27 -78
MCS0 30 -96
MCS7 24 -73
