MIKROTIK GPOE-16AB POE Injector Gigabit 16Port

Detail MIKROTIK GPOE-16AB POE Injector Gigabit 16Port

MIKROTIK GPOE-16AB 16Port Gigabit POE INJECTOR

GPOE-16AB Injector / Splitter Untuk 16 perangkat dengan standart PoE 802.3at dan PoE+ dengan Gigabit ethernet.
Support power supply external 12v - 56v up-to 60 watt dengan pilihan PoE mode-A (1,2,3,6) dan mode B (4,5,7,8).

16 Port Gigabit Ethernet Injector
16 Shielded RJ-45 LAN
16 Shielded RJ-45 LAN+POE
all 4 data pairs active for gigabit data rates
shared data and power via transformer isolated power injection on A and B mode pairs
1U high standard rack mount (1.75 x 19 x 2 inches)
650 ma automatic resettable fuse on each port, one for each mode
power is equally shared as needed by the devices
Use with any Ethernet switch passes all management info transparently
4 LED status indicators :
GReen LED = 1 master power
for each group of 4 POE sockets:
* 0 to 20 ma - LED off
* 20 to 300 ma - LED Green
* over 300 ma - LED Yellow
Ideal for IP Cameras, VOIP phone, WiFi Access Points with 802.3af or 802.3at or passive
Technical Support: poe-world.com
Power supply range 24 to 56 volts
Dual Power supply inputs (2.1mm x 5.5mm) see table below
we offer kits with power supplies

Environmental:
operating temperature range 0 to 50 deg C
storage temperature range 0 to 50 deg C
relative humidity range 5 to 90% non condensing
FCC rules there are no RF emitting devices in the design
the device is PELV per NFPA standard 79 protected extra low voltage
no cooling is required, no fans. Quiet operation with no moving parts
