MikroTik CRS504-4XQ-IN Cloud Router Switch 504 4XQ IN.

Detail MikroTik CRS504-4XQ-IN Cloud Router Switch 504 4XQ IN.

Overview Of MikroTik CRS504-4XQ-IN Cloud Router Switch 504 4XQ IN
Mikrotik CRS504-4XQ-IN
Details
Product code CRS504-4XQ-IN
Architecture MIPSBE
CPU QCA9531
CPU core count 1
CPU nominal frequency 650 MHz
Dimensions 320 x 185 x 44 mm
RouterOS license 5
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 70°C
Powering Details
Number of AC inputs 2
AC input range 100-240
Number of DC inputs 3 (DC jack, PoE-IN, 2-pin terminal)
DC jack input Voltage 36-57 V
2-pin terminal input Voltage 36-57 V
Frequency (Hz) 47-63
Max power consumption 41 W
Max power consumption without attachments 25 W
Cooling type 2
PoE in 802.3 bt
PoE in input Voltage 43-57 V
Ethernet Details
10/100 Ethernet ports 1
Fiber Details
Number of 100G QSFP28 ports 4
Peripherals Details
Serial console port RJ45
Other Details
CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals
Details
Certification CE, EAC, ROHS
IP 20
