MikroTik CRS305-1G-4S+IN

Detail MikroTik CRS305-1G-4S+IN

MikroTik CRS305 is a compact yet very powerful switch, featuring four SFP+ ports, for up to 10 Gbit per port. The device has a 1 Gbit copper ethernet port for management access and two DC jacks for power redundancy. The device is a very sleek and compact metallic case without any fans, for silent operation. The device has a Dual boot feature that allows you to choose between two operating systems - RouterOS or SwOS. If you prefer to have a simplified operating system with only switch specific features, use SwOS. If you would like the ability to use routing and other Layer 3 features in your CRS, use RouterOS. You can select the desired operating system from RouterOS, from SwOS or from the RouterBOOT loader settings. All the feature set comes with a disruptive price, providing the best price/performance on the market.

Product Features

4 SFP+ ports
1 Gigabit Ethernet ports
Non-Blocking throughput: 41 Gbps
Switching capacity: 82 Gbps
Forwarding rate: 61 Mpps
2 DC jack for redundancy
Maximum power consumption: 12 W (with attachments 18 W)
Supports PoE+ IEEE 802.3at/af and passive PoE 12-57 V
Metal enclosure
Fanless

Product Specifications

Product code CRS305-1G-4S+IN
CPU 98DX3236A1 800 MHz
RAM 512 MB
Storage type Flash
Storage size 16 MB
Switch chip model 98DX3236A1
10/100/1000 Ethernet ports 1
SFP+ cages 4
Operating system SwOS / RouterOS (Dual boot)
PoE in Yes
Supported input voltage 12 - 57 V (DC jack and PoE in)
Number of DC jacks 2
Operating temperature -40C .. +70C tested
Max power consumption 12 W
License level 5
