Mikrotik CCR2216-1G-12XS-2XQ Core Router 12x SFP28 25G 2x QSFP28 100G

Detail Mikrotik CCR2216-1G-12XS-2XQ Core Router 12x SFP28 25G 2x QSFP28 100G

Mikrotik CCR2216-1G-12XS-2XQ Cloud Core Router 12x SFP28 25G + 2x QSFP28 100G
Details
Product code CCR2216-1G-12XS-2XQ
Architecture ARM 64bit
CPU AL73400
CPU core count 16
CPU nominal frequency 2000 MHz
RouterOS license 6
Operating System RouterOS 7
Size of RAM 16 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -20°C to 60°C
Powering Details
Number of AC inputs 2
AC input range 100-240
Max power consumption 128 W
Max power consumption without attachments 80 W
Cooling type 4
Ethernet Details
10/100/1000 Ethernet ports 1
Fiber
Details
Number of 25G SFP28 ports 12
Number of 100G QSFP28 ports 2
Peripherals Details
Serial console port RJ45
Number of M.2 slots 2
Other Details
CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals Details
Certification CE, EAC, ROHS
IP 20

Gambar produk
