Hardware configuration Processor: Qualcomm® IPQ5000 Dual-core A53 1.0GHz CPU Network processing unit: Single core 1.0GHz NPU Memory: 256MB 2.4G Wi-Fi: 2×2 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate is 574Mbps) 5GHz Wi-Fi: 2×2 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate is 2402Mbps) Antennas: High gain antennas Heat dissipation: Natural heat dissipation Total ports: 1×10/100/1000Mbps self-adaptive WAN port (Auto MDI/MDIX) 3×10/100/1000Mbps self-adaptive LAN ports (Auto MDI/MDIX) LED indicator light: 2 lights, System indicator × 1, Internet indicator × 1 System reset button: ×1 Mesh networking button: ×1 Power input port: ×1 Protocol standards: IEEE 802.11a/b/g/n/ac/ax,IEEE 802.3/3u/3ab
Wireless specifications Dual-band: 2.4GHz, 5GHz Modulation: 11b:DSSS:DBPSK(1Mbps),DQPSK(2Mbps),CCK(5.5/11Mbps) 11a/g:OFDM:BPSK(6/9Mbps),QPSK(12/18Mbps),16QAM(24/36Mbps), 64QAM(48/54Mbps) 11n:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM. Data rate:MCS0-MCS15 11ac:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM. 11ax:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM. Data rates: MCS0-MCS11 (supports 2 streams).
Software specifications Operating system: MiWiFi ROM, a smart router operating system based on OpenWRT WiFi Encryption: WPA-PSK/WPA2-PSK/WPA3-SAE encryption, Wireless access control (black and white list), SSID hidden Management applications: Supports Web, Android, iOS
Working Environment Working environment Temperature: 0-40℃ Operating humidity: 10%-90%RH (non-condensing) Storage temperature: -40-70℃ Storage humidity: 5%-90%RH (non-condensing)
