MIJIA ELECTRIC SCOOTER ESSENTIAL - Kick Scooter Skuter Elektrik

Detail MIJIA ELECTRIC SCOOTER ESSENTIAL - Kick Scooter Skuter Elektrik

Mi Electric Scooter Essential

PRODUCT SPECS

Product model number
DDHBC08NEB

Max. speed
20km/h (Max speed for each mode: Pedestrian mode: 5km/h; D: 15km/h; S: 20km/h)

General range
20km

Max. climbing angle
10°

Braking
E-ABS and disc brake

Rated power
250W

Max. power
500W

Tires
8.5" front and rear pneumatic tires

Controller undervoltage
protection
29V ± 0.5V

Controller current limit
17A±0.5A

Motor type
Brushless low speed
DC motor

Max.load
100kg

Rider height
120cm-200cm

Rider age
16-50

Working temperature
-10°C to 40°C

Storage temperature
-20°C to 45°C

IP-rating
IP54

Charging time
3.5 hours

AC POWER CABLE

Plug type
2 straight prong

Tail type
8-shape

AC wire
H05VVH2-F

AC cable length
2.0m

ADAPTER SPECS

Input voltage
100-240VAC 50/60Hz

Input current
2A MAX

Output voltage
42VDC

Output current
1.7A

Output power
71W

DC cable length
2m

DC cable port type
Custom Φ8.0*1.6mm

BATTERY SPECS

Battery type
Lithium ion battery

Battery model
NE1002-H

Maximum charging voltage
42VDC

Rated voltage
36VDC

Rated capacity
5100mAh /183Wh

Charging temperature range
0°C — 40°C

Discharge temperature
range
-20°C — 50°C

Storage time
Approx. 13 months

Battery weight
1.1kg

Cyclical lifetime
500 charging cycles with
power maintained above 70%

Gambar produk
