Detail Metal Inductive Sensor Proximity Sensor Switch Detection NPN NO DC 5-36VDC

Inductive Proximity Sensor Switch For Metal Object LJ12A3-4-Z/BX NPN NO

Digunakan untuk mendeteksi objek berbahan logam, model 3 wire, range oprasi yang luas ( 6-36VDC) sehingga memudahkan dalam mensuplai tegangan yang dibutuhkan.

Spesification:
Type :3 Wire Type (Brown, Blue. Black)
Diameter of head :12mm
Detecting distance: 4mm
Supply voltage :DC 6-36V
Polarity: NPN
Switch: Normally Open (NO)
Current output :300mA
Response frequency: 0.5KHz
Cable Length :110cm/43.3''
External material: Plastic,Alloy
Colour: Blue / Yellow

Wiring:
Brown: +V
Blue: Output (0V)
Black: -V
