Detail Mercusys MW306R 3Antenna 300Mbps Wireless N Router
Wireless Standards IEEE 802.11 b/g/n Frequency 2.4-2.5 GHz WiFi Speeds • 11n: Up to 300Mbps (Dynamic) • 11g: Up to 54Mbps (Dynamic) • 11b: Up to 11Mbps (Dynamic) Reception Sensitivity • 270M: -70dBm@10% PER • 11M: -87dBm@10% PER • 130M: -72dBm@10% PER • 6 M: -92dBm@10% PER • 54M: -74dBm@10% PER • 1 M: -94dBm@10% PER Transmission Power <20dBm (EIRP) Wireless Security WPA-PSK/WPA2-PSK Wireless Functions Enable/Disable Wireless Radio, WDS Bridging
WAN Type Dynamic IP/Static IP/PPPoE/PPTP/L2TP Management Access Control Local Management Remote Management DHCP DHCP Server, DHCP Client List Port Forwarding Virtual Server, UPnP, DMZ Firewall Security IP and MAC Address Binding Guest Network 2.4GHz Guest Network
Dimensions 5.8 × 4.5 × 1.3 in (147 × 115 × 34 mm) Button RESET/WPS Button External Power Supply 5V/0.6A Antenna Type 3* Fixed Antennas Ethernet Ports 1* 10/100Mbps WAN Port, 3* 10/100Mbps LAN Ports
Package Contents Wi-Fi N Router (MW306R) Power Adapter Quick Installation Guide Ethernet Cable
