MCP2551 High Speed CAN Communication Protocol Controller

Detail MCP2551 High Speed CAN Communication Protocol Controller

MCP2551 High Speed CAN Communication Protocol Controller

The CJMCU 2551 is a fault tolerant high speed CAN device that acts as a CAN
protocol controller and a physical bus interface. The MCP2551 provides
differential transceiver capability for the CAN protocol controller, which fully
complies with the ISO 11898 standard, including 24V voltage requirements.

Typically, each node on the CAN system must have a device that converts the
digital signal generated by the CAN controller into a signal suitable for bus
transmission.

It also adds buffers between the CAN controller and the high voltage spikes on
the CAN bus, which may be generated by external devices.

Support 1MB S operating rate.

Meet the ISO 11898 standard physical layer requirements.

Suitable for 12V and 24V systems. Slope External Control, Reduced RFI.

Automatically detects a ground fault at the TXD input.

Power on reset and voltage event undervoltage protection.

No power up node or undervoltage does not affect the CAN bus.

Low current standby operation.

Up to 112 nodes can be connected.

Material: Metal

size: 18 x 15mm

Colour: Purple

Quantity: 1 pcs

Package Contents: 1 x CAN Communication Protocol Controller Bus Interface Module

Note: Light shooting and different displays may cause the color of the item in
the picture a little different from the real thing. The measurement allowed
error is 1 3cm.

Gambar produk
