Marshall V-LCD70MD 7 On-Camera Monitor with HDMI and Modular / Camera Monitor

Detail Marshall V-LCD70MD 7 On-Camera Monitor with HDMI and Modular / Camera Monitor

The Marshall Electronics V-LCD70MD 7" On-Camera Monitor with HDMI and Modular SDI Upgrade Option is a top-quality camera monitor with superior internal components and an advanced set of focus, exposure, and sound-assist tools. The display is a high-resolution, high-contrast, high-brightness display and is polycarbonate-coated for scratch resistant protection. It's LED backlit for additional brightness and it is equipped with IPS technology allowing an enhanced viewing angle from farther and farther away. The operating system is icon-driven.

Connections consist of a native HDMI input and output, and 3G-SDI inputs and outputs can optionally be installed by screw-on modules. The HDMI input gives you 8 channels of de-embedded audio to pick up and monitor. You can monitor the audio on-screen on a dual-bar Waveform display or/and with headphones via the monitor's headphone output. With headphones, you can monitor any pair from the available channels.

For mounting, a 1/4"-20 screw-hole is available on every side of the monitor. And for power, a power supply comes included and additionally any of a very long list of batteries can optionally be attached. (Please see the Specifications tab for the full list. Battery adapters are sold separately.)
Overview
High Resolution 1024 x 600 LED backlit IPS panel
DSLR Ratio Adjustment with 4 DSLR ratio presets
On screen Waveform / stereo audio bar display
Manual Gamma adjustment
Adjustable IRE Clip Guide (Zebra filter)
Stereo headphone output (select a L+R pair from the available channels)
6 monitor configuration user presets
Custom screen markers (choice of four colors and variable lines widths)
HDMI Auto Color Space and Ratio Detect
New Peaking filter (choice of four color highlights and variable sensitivity)
False Color filter
Four user assigned function buttons with 32 possible uses
Pixel-to-Pixel panning (Custom Pixel-to-Pixel Mode)
15:9, 16:9, 4:3 Pixel-to-Pixel modes
Input Crop with automatic scaling
RGB Check Field with Monochrome
DSLR Ratio Adjustment
Lets you scale video that does not completely fill the monitor's screen when connected by HDMI in "Record" mode on certain Canon DSLRs. You can scale DSLR video output, fill the screen, and eliminate black pillar bars with a variety of options to choose select, from Normal, to 3:2, 16:9, and Full Screen. DSLR Ratio Adjustment is programmable to one of the four user-configurable buttons on the front panel.
Waveform and Audio Clip Guide
The monitor incorporates both a Waveform display and Stereo Audio bars. These may be displayed separately or together in any one of the four corners of the monitor. The Stereo Audio is de-embedded from either the input.
Zebra Clip Guide
The Zebra function visually filters parts of images under a Lower Threshold or over an Upper Threshold. Data on either side of the filters can be displayed with a custom color. Zebra can also be inverted to filter the area between the Upper and Lower Threshold. The color selected for the Lower
